High-Speed Pick Place Machine
❙ Features Yamaha Pick and Place Machine
Yamaha pick and place machine applicable PCB: L510x~W460mm to L50x~W50mm, Applicable components: 0402(Metric base) to □32*mm components*1 *Correspondence since Jan., 2010, Placement Speed: 36,000CPH（0.1sec/CHIP Equivalent）
1. This compact platform design (front view breadth 1,254mm) assure flexible line arrangement in your site
❙ Specification of Yamaha Pick and Place Machine
|YS12 (Model : KHY-000)|
|Applicable PCB||L510x~W460mm to L50x~W50mm|
|Through-put (Optimum)||36,000CPH（0.1sec/CHIP Equivalent）|
|Mounting accuracy (Yamaha's standard components)||
Absolute accuracy (μ+3σ) : +/-0.05mm/CHIP
Repeatability(3σ) : +/-0.03mm/CHIP
|Applicable components||0402(Metric base) to □32*mm components *Correspondence since Jan., 2010|
|Number of component types||120 types(Max, 8mm tape reel conversion)|
|Power supply||3-Phase AC 200/208/220/240/380/400/416V +/-10% 50/60Hz|
|Air supply source||0.45MPa or more, in clean, dry states|
L1,464(End of extension conveyor)xW2,018(End of guide for feeder carriage)xH1,455mm(cover top)
